Manufacturer Of High Precision Customised Metal Components
Is Currently One of the leading Production company in India For Customised Metal Components.
If You are looking For a specially engineered components or assembly but don't have the resources or expertise to design and manufacture it yourself, Star Industries offers a complete design, engineering and manufacturing service, to translate idea's and concepts into volume production.
Regardless of how complex is your design, assembling or quality challenge, our mission is to provide you with the most efficient, innovative and cost effective solution.
We Maintain Tolerance (0.005,0.01). We Specially Work On High Precision Components and High Precision Tolerance.
We Specially Work On Special Alloys Like A Titanium, Nickel Alloys, Carbon, Beryllium Copper, Stainless Steel, Milde Steel, Aluminium, And All Special Alloys As Per Customer Requirements.(Specially Brass And Copper Alloy.)
We are manufacturer, supplier & Exporter of Customised Components In All Metals, Cnc & Vmc Turned Parts, Precision components, Automobile parts,Fitting parts,Gas fitting parts, Fasteners Products, Electrical and electronics parts, Aerospace & Defence Components and Customised parts as per customer requirements.
We are one of the pioneers & leading manufacturers of Customised Components for variety of usage. We have been making these components for diversified of industries, the product spectrum is very wide. We offer wide range of products as mentioned above.
We offer a very competitive rate.
Our contiguous efforts to provide a quality & cost effective products has given us opportunity to serve many of the premier industries in India.
Our contiguous efforts to provide a quality & cost effective products has given us opportunity to serve many of the premier industries in India.Our contiguous efforts to provide a quality & cost effective products has given us opportunity to serve many of the premier industries in India.
We believe in maintaining quality. To achieve this we take measure to check quality at each stage of manufacture from receiving in progress to final despatch.
We believe confidence of customer can be acquired by providing ( Timely delivery, competitive cost, consistency in quality.)
The company has always considered its focus on quality as the main tool to obtain significant buisness results.
Product & Service
Fasteners & Customised Fasteners As Per Your Requirement
High Precision Customised Machining Service
High Precision Customised Machining Service
Fasteners & Customised Fasteners As Per Your Requirement
High Precision Customised Machining Service
* Swiss-style turning capable of part diameters from 0.630″ (16 mm) down to 0.030″ (0.762 mm) and part lengths from 0.063″ (1.6 mm) to 4.0″ (101.6 mm)
* As-machined surfaces as smooth as Ra 16 microinch (Ra 0.40 μm) with additional polishing available
* Precision machining services including turning, milling, boring, drilling, hexing, polishing, slotting, and threading
* Ability to serve the micro-machining market with a specialty in small batch, fast turnaround jobs
* Turning shorter parts with smaller diameters, in larger volumes, and higher Cpk and Ppk values than machining alone.
* High volume and lights out capabilities
Fasteners & Customised Fasteners As Per Your Requirement
Fasteners & Customised Fasteners As Per Your Requirement
Fasteners & Customised Fasteners As Per Your Requirement
The Different Types of Fasteners and Their Uses
Fasteners are used to mechanically join two or more objects together, either permanently or non-permanently. There are many different types of fastener, each with their own purpose.
Fasteners can broadly be categorised as either Permanent or Non-Permanent. Permanent Fasteners, such as rivets and nails, are single-use fasteners that are designed to permanently join two materials or parts. Removing the fastener destroys it.
Non-Permanent fasteners, on the other hand are designed to allow for easy removal and re-use. Fasteners such as bolts and screws are commonly used in a number of industries and products as they allow for parts to be dissassmbled and re-assembled if required. Non-Permanent fasteners can be threaded (bolts, screws, etc.) or non-threaded (pins, retaining rings, etc.).
Threaded Fasteners
Threaded fasteners are among the most commonly used for assembling components due to the ease in which they can be installed and uninstalled as needed. There are three main types of threaded fastener; Bolts, Screws and Studs.
Bolts have a head on one end (this is usually a hex head) and are threaded on the other. They are generally used in conjunction with a nut (and sometimes a washer) to hold them in place.
Screws are similar to bolts in that they have a head on one end and a thread on the other. They key difference is thet screws are usually used to screw into an internally threaded hole. There are many different types of screws, such as Cap Screws, Machine Screws, and Woodscrews.
Studs are threaded on both ends, and therefore have no head. They are used to join two components with internally threaded holes together.
Fastener threads are standardised to two major standards: ISO (Metric) and ANSI (Unified). Threads can also be right-handed or left-handed, depending on the application. However, the majority of common fasteners are right-hand threaded.
Types of Threaded Fastener
Bolts and Setscrews - Bolts and Setscrews usually feature a hexagonal head with a thread, and can be used either in conjunction with a nut or in a threaded hole. Bolts generally have a shank beneath the head, while Setscrews are threaded all the way up to the head.
Carriage Bolts - Also known as Cup Square Hex Bolts, these have a smooth rounded head with a square beneath. They are used for securing metal to wood.
Eye Bolts - These bolts have a circular ring instead of a traditional head and are used to fix rope or chain to a surface.
U-Bolts - These bolts are used for attaching round objects such as pipes and tubes to a wall or other surface.
Wood Screws - Featuring a smooth shank and tapered point, these screws are used in wood and come in different head shapes such as Philips, Slotted or Pozidriv.
Machine Screws - Machine Screws are used with a nut or tapped hole. Thread Cutting Machine Screws are also available, which feature a thread cutting point.
Self-Tapping Screws - Often referred to as Self-Tappers, these screws are used for in sheet metals. Self-tapping screws tap their own thread.
Socket Screws - These screws feature a smooth shank and an Allen head, and are fastened using an Allen key. Socket screws come with different head shapes, such as Button, Socket Cap and Countersunk.
Grub Screws - Grub screws are a special type fo screw which usually do not have a head. They are used to prevent movement or rotation between two parts.
Nuts
Nuts are used in conjunction with a bolt to clamo two or more parts together. The most common type of nut is a Hexagonal Nut, but there are several different types of nuts for use in different applications.
Hex Nuts - A plain, hexagonal nut with an internal thread. These are by far the most common type of nut, and are used in numerous industries and applications.
Lock Nuts - These nuts are used when the nut needs to be locked in place without clamping on to another object.
Nylon Insert Nuts - Commonly referred to as a Nyloc nut, these hexagonal shaped nuts have a nylon insert which prevents the nut from coming loose due to vibration.
Shear Nuts - These cone shaped nuts feature a hexagonal gripping point which snaps off when the maximum torque has been reached, leaving just the cone-shaped nut which is difficult to remove.
Wing Nuts - Commonly used in applications where the nut needs to be removed often, Wing Nuts feature two external "wings" which allow for manual turning.
Washers
Washers are commonly used between the head of a bolt, screw or nut and the material they are clamping. Their primary function is to increase the bearing area of the head whilst also protecting the material underneath from damage. There are several different types of Washer, each with their own uses.
Flat Washers - These are the most common type of washer and are used to evenly distribute the load of the bolt, screw or nut as the fastener is tightened.
Spring Washers - These locking washers are designed to stop the bolt, screw or nut from vibrating loose.
Cup Washers - Cup Washers form a cup for the head of the fastener to fit in, creating a flush finish with the fastener head. They are used in conjunction with a wood screw.
Repair Washers - Also commonly referred to as Penny Washers or Fender Washers, they feature a small inside diameter hole and are design to create a greater bearing surface and prevent pull-through.
Rivets
Rivets are a permanent fastener, in that once removed, they cannot be re-used. Rivets are used in a number of industries and applications but are most commonly used to join metal sheets and plates.
Pop Rivets - Consisting of a hat and mandrel, Pop Rivets are used to join two materials together. During installation, the mandrel is forced into the rivet body, forcing the body to expand and grip onto the material(s). Once gripped, the remaining mandrel snaps off.
Large Flange Pop Rivets - Large Flange Pop Rivets are similar to Pop Rivets in their application but feature a much large flange.
Multi-Grip Rivets - These rivets are used when joining materials with differing thicknesses, which would normally require multiple rivet sizes. They are very versatile and cost-effective.
Customised Fasteners As Per Your Requirement As Per Your Drawing As Per Your Samples.
Aerospace CNC Turned Metal Components
Aerospace CNC Turned Metal Components
Fasteners & Customised Fasteners As Per Your Requirement
Star Industries provides custom made parts through an extensive network of carefully vetted and certified CNC lathes and turning centers provided by our manufacturing Unit. Whatever the part you need, we can guarantee we have the experience and equipment to make it. The efficiency of our manufacturing process ensures a high standard of product quality, exceptional part complexity, and superior surface finishes, all created through Star Industries and delivered exactly when you need it.
Fitting & Customised Fitting Parts
Aerospace CNC Turned Metal Components
Fitting & Customised Fitting Parts
A fitting or adapter is used in pipe systems to connect straight sections of pipe or tube, adapt to different sizes or shapes, and for other purposes such as regulating the fluid flow.
A pipe fitting is used in plumbing system to join multiple pipes of same size or different sizes, to regulate the flow or to measure the flow. They are made up of different materials like copper, iron, brass, PVC etc.
Hydraulic fittings come in a wide range of types and applications. They are used to connect the hydraulic hose to components like hydraulic cylinders, pipes, tubes, or different types of hydraulic hoses in hydraulic systems.
The different types of hydraulic fittings allow the fluid to flow, change its direction, divert, or mix. These fittings should be capable of creating a tight seal and preventing leakage in the application. These fittings are widely used in hydraulic-powered applications including plumbing, robotics, assembly lines, and heavy equipment.
Pneumatic fittings are parts used to connect sections of pipe, tube, and hose in pneumatic (pressurized gas) systems. Compared to hydraulic fittings, pneumatic fittings are typically characterized by tighter seals and lower pressure requirements. They are frequently used in pneumatic logic control systems and instrumentation.
People use AN fittings because they look cool and provide a secure fitting that seals hoses better than traditional push on nipples and hose clamps. They form a serviceable connection that provides a reliable seal.
A grooved fitting, also known as a grooved coupling, has four elements: grooved pipe, gasket, coupling housing, and nuts and bolts.
Pipe fittings, also known as pipe connectors, attach one pipe to another in order to lengthen the run or change the flow direction in a plumbing system. These are used to combine, divert or reduce the flow of the water supply, and they come in a variety of sizes to fit the pipe they will connect.
Some common materials used to make fittings include PVC, PE, ABS, PP, nylon, aluminium, stainless steel, steel, copper, cast iron and brass.
Electrical & Electronics Metal Components
Electrical & Electronics Metal Components
Electrical & Electronics Metal Components
The electronic components are used in various applications, such as automation, robotics, biomechanics, power electronics, mechatronics, renewable energy applications, photo voltaic systems, etc.
Automobile & Automotive Parts
Electrical & Electronics Metal Components
Electrical & Electronics Metal Components
To meet the different requirements of our valuable customers, we are manufacturing high-quality CNC turning auto parts at competitive prices that are provided in a wide variety of specifications according to the exact requirements of customers. We provide customize auto parts CNC Machining Services, turning lathe services, milling, grinding, wire EDM cutting, bending, stamping, laser cutting and other metal fabrication.
We have rich experience, fast delivery time, excellent service and competitive price. The offered precision CNC Machining Services, turning lathe services, milling, grinding, wire EDM cutting, bending, stamping, laser cutting and other metal fabrication. We have rich experience, fast delivery time, excellent service and competitive price. The offered precision CNC Turning Parts are best suited for fitting purpose in the automobile industry such as throttle control shaft, low pass filter shaft, hydraulic valve, valve housing, sensor Housing, temperature sensor housing, pressure sensor housing, pipe Joint, sensor metal shell, etc. Known for its anti-corrosive and accurate dimension. The CNC machined automotive parts are according to international standards using the premium quality components and sophisticated technology under the supervision of our expert team.
Metal Hardware Parts
Electrical & Electronics Metal Components
Metal Hardware Parts
At Star Industries, we offer a range of metal hardware and fabrication services to suit your budget and timeline. Our high-end machinery and experienced team can produce custom designs, including those requiring complex geometries or high precision.
At Star Industries, we work with a variety of metal materials to meet customer specifications. Hardware components are mainly composed of aluminum or regular steel, but we have other materials such as:
Brass
Beryllium copper
Copper
Titanium
Stainless steel
Carbon steel
Other alloys and superalloys
Our Facilities
Our Facilities
Metal Hardware Parts
Star Industries Is Groups Of Companies.
Our Partner Companies.
1. Star Industries
2. Bhagvati Brass.
3. Prominent Technology.
4. Purusharth Turnometics.
5. Vraj Precision.
6. Haya Fasteners.
We Are ISO 9001 - Certified Manufacturers.
100000 Square Feet At Different Different Destinations.
Best Quality Testing Equipments.
Well trained team.
In House High Standard Manufacturing Facilities.
In House Forging & Plating Plants.
In House Foundry & Extrusion Plant
Machining In All Metals Like A Brass, Stainless Steel All Grades, Mild Steel, Titanium, Nickel Alloys, Copper, Copper Beryllium, Aluminium And All Special Gardes And Special Alloys As Per Customer Requirements.
